Printing Technology |
CrystalPoint Technology |
|
Applications |
Colour and B&W Technical drawings, Maps, unfolded and folded, POP/POS posters, Graphic Arts applications like posters, wallpapers, banners, wrapping paper, fine art |
|
Productivity |
4 D/A1 per min |
|
Print Modes |
9 print modes and PA (Print Assistant®, automatically determines the best print mode based on the content, without intervention required) |
|
Print Resolution |
600 x 600 dpi |
|
Resolution Droplet Aligning Accuracy |
1,200 dpi |
|
Minimum Line Width |
0.08 mm |
|
Description |
Integrated Contact Image Sensor (CIS) Colour scanner with Image Logic technology |
|
Resolution |
600 x 600 dpi |
|
Scan Speed |
15.2 m/min Black & white scanning |
|
Scan Formats |
TIFF, PDF, PDF/A, JPEG, CALS, multi-page PDF, multi-page PDF/A and multi-page TIFF |
|
Scan Protocols |
FTP, SMB, scan to cloud |
|
Minimum Original Width |
208 mm |
|
Original Length |
208 mm - 16,000 mm |
|
Original Thickness |
Maximum 0.8 mm |
|
Media Rolls |
Default is 4 rolls |
|
Media Weight |
60 - 200 g/m² |
|
Media Thickness |
Paper: 800 μm; 30 mil |
|
Roll Length |
Up to 200 m |
|
Roll Width |
297 - 1,067 mm |
|
Roll Diameter |
Up to 180 mm |
|
Roll Core Diameter |
7.62 cm and 5.08 cm ( 3 in and 2 in ) cores |
|
Roll Weight |
Up to 20 kg |
|
Minimum Printed Length |
210 mm |
|
Maximum Printed Length |
200 m |
|
Media Type |
Uncoated papers, uncoated tyvek, self-adhesive papers, self-adhesive coated vinyls, blue back papers, textile types, polypropylene films, polyester films, light block films, canvas, soft banner, instant dry photo paper, coated & uncoated non-woven wall paper (fleece), backlit film, wall paper, several natural and synthetic textiles |
|
Description |
High performance POWERsync controller with Windows 10 iOT LTSC, 64 bits |
|
Processor |
6 Core, 6 Thread, Core i5-8500 @4.10 GHz |
|
Memory |
2 x 8 GB DDR4 |
|
Hard Disk |
2x 500 GB, 7,200 rpm (standard) |
|
Supported File Format |
TIFF, JPEG, HPGL, HPGL2, DWF, C4, Calcomp 906/907/951, CALS, NIRS/NIFF |
|
Supported File Format (Optional) |
Postscript/PDF license (Adobe PostScript 3 & PDF1.7) |
